- New connector requires no special terminals
- User can easily retrofit any, old siren harness with only a wire stripper and screw driver
- 26 Programmable siren tones including:
- 2 Approved yelp tones
- Simulated mechanical wail & manual
- 8 Air horn tones
- 7 Position audio tone function select knob
- Self-resetting circuit protection against speaker shorts
- Integrated public address microphone, volume adjustable from front of siren
- Diagnostic LED
- On/off rocker switch
- Positive switching for Aux
- Aux enable can be used to enable a siren/air horn tone; or for hands free tone cycling
- Radio rebroadcast volume adjustable from front of siren
- Reverse polarity protection
- High and low voltage shutdown protection
- Operates one 100 watt speaker
- Reverse polarity protection
- Ships complete with positive locking connector, mic clip, mounting bracket, hardware, and instructions
- Dimensions: 2”H x 6”W x 4 11/16" D
- Weight: 5 lbs.
- Output: 100 watts (1 speaker)
- Voltage: 10-16V DC
- Frequency: 675-1633Hz
- Amp draw: 8 amps
- Stand-by current switch off: 0.004A
- Exceeds acoustical and environmental requirements SAE J1849*, CA Title 13 Class A* (* when used with SVP drivers and approved tones)
SS670 Siren Amplifier REV A - Manual
SS670 Siren Amplifier REV B - Manual
SS670 Siren - Product Flyer
Alert
Two Tone
Yelp
Manual
Phaser
Wail
Horn
Air Horn and Yelp
Air Horn II
Continuous Beep
Continuous Tone
Double Post Pop Air
Ghost
Hoot
LF Air Horn
Manual No Run Down
Max Yelp
Mech Manual Rundown
Mech Wail
Rapid Ghost
Rapid AH
Rapid Hoot
Single AH
Single Quick AH
Standard Air Horn
TT AH
